流水线并行¶

import numpy as np
import os
import paddle
from paddle.distributed import fleet
from paddle.fluid.dygraph.container import Sequential
import paddle.nn as nn
from paddle.fluid.dygraph.layers import Layer
from paddle.distributed.fleet.meta_parallel import LayerDesc, PipelineLayer
import paddle.nn.functional as F
import paddle.distributed as dist
import random
from paddle.io import Dataset, BatchSampler, DataLoader

strategy = fleet.DistributedStrategy()
model_parallel_size = 1
data_parallel_size = 1
pipeline_parallel_size = 2
strategy.hybrid_configs = {
    "dp_degree": data_parallel_size,
    "mp_degree": model_parallel_size,
    "pp_degree": pipeline_parallel_size
}
strategy.pipeline_configs = {
    "accumulate_steps": BATCH_SIZE // MICRO_BATCH_SIZE,
    "micro_batch_size": MICRO_BATCH_SIZE
}

fleet.init(is_collective=True, strategy=strategy)

def set_random_seed(seed, dp_id, rank_id):
    random.seed(seed)
    np.random.seed(seed + dp_id)
    paddle.seed(seed + dp_id + rank_id)
    print("seed: ", seed)
    print("rank_id: ", rank_id)
    print("dp_id: ", dp_id)

hcg = fleet.get_hybrid_communicate_group()
world_size = hcg.get_model_parallel_world_size()
dp_id = hcg.get_data_parallel_rank()
pp_id = hcg.get_stage_id()
rank_id = dist.get_rank()
set_random_seed(1024, dp_id, rank_id)

class ReshapeHelp(Layer):
    def __init__(self, shape):
        super().__init__()
        self.shape = shape

    def forward(self, x):
        return x.reshape(shape=self.shape)


class AlexNetPipeDesc(PipelineLayer):
    def __init__(self, num_classes=10, **kwargs):
        self.num_classes = num_classes
        decs = [
            LayerDesc(
                nn.Conv2D, 1, 64, kernel_size=11, stride=4, padding=5),
            LayerDesc(nn.ReLU),
            LayerDesc(
                nn.MaxPool2D, kernel_size=2, stride=2),
            LayerDesc(
                nn.Conv2D, 64, 192, kernel_size=5, padding=2),
            F.relu,
            LayerDesc(
                nn.MaxPool2D, kernel_size=2, stride=2),
            LayerDesc(
                nn.Conv2D, 192, 384, kernel_size=3, padding=1),
            F.relu,
            LayerDesc(
                nn.Conv2D, 384, 256, kernel_size=3, padding=1),
            F.relu,
            LayerDesc(
                nn.Conv2D, 256, 256, kernel_size=3, padding=1),
            F.relu,
            LayerDesc(
                nn.MaxPool2D, kernel_size=2, stride=2),
            LayerDesc(
                ReshapeHelp, shape=[-1, 256]),
            LayerDesc(nn.Linear, 256, self.num_classes),  # classifier
        ]
        super().__init__(
            layers=decs, loss_fn=nn.CrossEntropyLoss(), **kwargs)

model = AlexNetPipeDesc(num_stages=pipeline_parallel_size, topology=hcg._topo)
scheduler = paddle.optimizer.lr.PiecewiseDecay(
        boundaries=[2], values=[0.001, 0.002], verbose=False
)
optimizer = paddle.optimizer.SGD(learning_rate=scheduler,
                                parameters=model.parameters())
model = fleet.distributed_model(model)
optimizer = fleet.distributed_optimizer(optimizer)

for i, (image, label) in enumerate(train_reader()):
    if i >= 5:
        break
    loss = model.train_batch([image, label], optimizer, scheduler)
    print("pp_loss: ", loss.numpy())
